Description
- Laser power : 30W
- Power consumed : 5kw
- Manufacturing line speed : ≤100m for every minute
- Min line width : 15mm
- Min character size : 4mm
- Jet interval time : more than 1mm
- Flying marker character rows : 1-10 rows
- Repetition accuracy :±0.01mm
- Laser wavelength : 6µm, angle of divergence: 7.5mrad
- Marking area : 100mm×100mm.
- Character marking speed : >500 characters for every second (conveyor belt speed is 27m
for every minute, 32 characters height: 3mm)
- Power supply requirement : AC 220V, 50HZ 5A
- Industrial protective grade : IP54
